Description
FEATURES
Ideal for attaching to concrete, steel or wood surfaces
Provides optimal support for high-performance data cable, up to and including Cat 5e, Cat 6, Cat 6A, Cat 7 and fibre optic
Ready to use out of the box, saving installation time and labor
Requires no screws, rivets or special tools for assembly
Single- or double-sided tree configurations provide multiple J-Hooks with one structural attachment
Provides superior fill capacity and load rating over most other non-continuous cable support alternatives
Complies with EN 50174-2
Meets ISO®/IEC 14763-2, ANSI®/TIA 568 and ANSI®/TIA 569
PRODUCT ATTRIBUTES
Material: Steel
Finish: Pregalvanized
Type: Double Sided
Diameter: 2"
Tiers: 2
Height: 10 1/4"
Width: 5 13/16"
Hole Size 2: 0.185"
Hole Size 1: 0.405"
A: 1 7/16"
B: 2"
Static Load 1: 240 lb
Static Load 2: 180 lb
ADDITIONAL PRODUCT DETAILS
Static loads represent maximum load limit of J-Hook tree. Static load limit of each J-Hook is 60 lb (270 N).
Refer to Static Load 1 when fastening J-Hook tree using Hole Size 1. Refer to Static Load 2 when fastening J-Hook tree
using Hole Size 2.
Non-continuous supports may not exceed spacing of 5' (1.5 m) per TIA 569-C.9.7 and EN 50174-2.
