Description
FEATURES
Ready to use out of the box with no field assembly required
Tool-free installation to electrical boxes, no hardware necessary
Easy, snap-on t-grid clips with push-button adjustability
Supports market-leading range of electrical box depths
Easily accommodates multiple boxes with additional nVent CADDY 512X Electrical Box Mounting Clip (sold separately)
Drop-wire attachment points at t-grid and electrical box clips
PRODUCT ATTRIBUTES
Material: Steel;Spring Steel
Finish: Pregalvanized;nVent CADDY Armour
T-Grid Span: 24"
Box Depth: 2 1/8";3 1/2"
Width: 2 3/4"
Ultimate Static Load 1: 50 lb
Ultimate Static Load 2: 50 lb
Complies With: UL® 514A
ADDITIONAL PRODUCT DETAILS
Refer to Ultimate Static Load 1 when used as a box support. Refer to Ultimate Static Load 2 when used as a luminaire
support with a drop wire.
512SA48 complies with UL® 514A only for luminaire support with drop wire.
Not for fan support.
WARNING
nVent products shall be installed and used only as indicated in nVent's product instruction sheets and training materials.
Instruction sheets are available at www.nvent.com and from your nVent customer service representative. Improper
installation, misuse, misapplication or other failure to completely follow nVent's instructions and warnings may cause
product malfunction, property damage, serious bodily injury and death and/or void your warranty.
