Product Overview
Our colored USB 2.0 cables combine functionality, performance, and value. Just plug-and-play for keyboards, mice, modems, printers, and other USB peripherals. Engineered to support high speed USB computers and devices, this cable provides robust throughput of 480 Mbps, 40 times faster than USB 1.1. Foil and braid shielding reduces EMI/RFI interference and twisted-pair construction reduces crosstalk thus ensuring high speed, error-free data transfer.
Connect a USB peripheral to a USB hub or computer port and get high performance WITH flexibility. With different colors, you can easily color-code your USB devices, so you remember which device is connected to which port.
Electrical Characteristics:
- Nominal Impedance with Tolerance - 90Ω±15%
- Nominal Compacitance - 131PF/M
- Nominal Velocity of Propagation - 12Mb/s
- DC Resistance - 28AWG 239Ohm/Km @20°C, 24AWG 94.2Ohm/Km @20°C
- Insulation Resistance - 10MΩ
Physical Characteristics:
Conductor 1 (x2)
- Material - Stranded Tinned Copper
- Size - 28AWG (7/0.127 TC)
- Insulation - HD-PE
- OD - 0.85mm
- Color - White/Green (twisted pair)
Conductor 2 (x2)
- Material - Stranded Tinned Copper
- Size - 24AWG (7/0.20 TC)
- Insulation - SR-PVC
- OD - 1.1mm
- Color - Red, Black
Drain Wire
- Material - Tinned Copper
- Size - 28AWG (7/0.12 TC)
Shield 1
- Material - Aluminum Mylar Wrap
Shield 2
- Material - Braided Copper
- Coverage - 65%
Jacket
- Material - PVC
- OD - 4.7mm
USB 2.0 A Connector
- Gender - Male
- Insulation - White PBT
- Contact Material - Gold Flash
- Shell Material - Nickel Plated
USB 2.0 B Connector
- Gender - Male
- Insulation - White PBT
- Contact Material - Gold Flash
- Shell Material - Nickel Plated
Hood Type
- Molded
Approvals - RoHS Compliant
Package Type - Polybag
