Description
Belden 9931 060100 RS232/423 Low Cap, #24-6c, FPO, O/A Foil+Braid, PVC Jkt, CM
Computer EIA RS-232/423 Cable, 24 AWG stranded (7x32) tinned copper conductors, Datalene® insulation, overall Beldfoil® (100% coverage) + tinned copper braid shield (65% coverage), drain wire, PVC jacket.
Ordering Details
- Manufacturer Part Number: 9931 060100
- Color: Chrome
- UPC/EAN: 612825264361
Product Overview
- Suitable Applications: RS-232 Extended Distance & RS-423 Applications; Computer Communications; Low Voltage Analog Signals (4-20mA, 0-10V, ...); Low Voltage Digital Control (24V, …); Line Level Audio; Panel Wiring
Construction Details
- Element: Conductor(s); No. of Elements: 6; Size: 24 AWG; Stranding: 7x32; Material: TC - Tinned Copper
- Element: Conductor(s); Material: PE - Polyethylene (Foam); Nom. Thickness: 0.013 in (0.33 mm); Nom. Insulation Diameter: 0.049 in (1.2 mm); Color Code: Black, White, Red, Green, Brown, Blue
- Shield Type: Tape; Material: Bi-Laminate (Alum+Poly); Coverage: 100%; Drainwire Type: 24 AWG (7x32) TC
- Shield Type: Braid; Material: Tinned Copper (TC); Coverage: 65%
- Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.035 in (0.89 mm); Nom. Diameter: 0.242 in (6.15 mm)
- Overall Cable Diameter (Nominal): 0.242 in (6.15 mm)
Electrical Characteristics
- Element: Conductor(s); Nom. Conductor DCR: 24 Ohm/1000ft; Nom. Capacitance Cond-to-Cond: 12 pF/ft (39 pF/m); Nom. Capacitance Cond-to-Other (Conds + Shield): 22 pF/ft (72 pF/m); Nom. Velocity of Prop.: 78%; Max. Current: 1.5 Amps per Conductor at 25ºC
- Nom Outer Shield DCR: 4.4 Ohm/1000ft (14 Ohm/km)
- UL Voltage Rating: 300 V (CM), 30 V (UL AWM 2919)
Mechanical Characteristics
- UL Temperature: 60°C (UL CM);80°C (UL AWM 2464); Operating: -30°C to +80°C
- Stationary Min.: 2.9 in (74 mm); Installation Min.: 2.9 in (74 mm)
- Max. Pull Tension: 68 lbs (31 kg)
- Bulk Cable Weight: 34 lbs/1000ft
Standards and Compliance
- Environmental Suitability: Indoor (Not Riser or Plenum), Indoor
- Sustainability: CA Prop 65
- Flammability / Reaction to Fire: UL 1685 UL loading , IEC 60332-1-2
- CPR Compliance: CPR Euroclass: Eca
- NEC / UL Compliance: Article 800, CM
- AWM Compliance: AWM 2919
- CEC / C(UL) Compliance: CM
- European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
- UK Regulation Compliance: UKCA Mark
- APAC Compliance: China RoHS II (GB/T 26572-2011)
Product Notes
- Notes: Datalene® insulation features include a low dielectric constant and a low dissipation factor for high-speed, low-distortion data handling. Physical properties include good crush resistance and light weight.
History
- Update and Revision: Revision Number: 0.537 Revision Date: 09-07-2025
- Footnote: C - CRATE REEL PUT-UP.
