Belden 9892 0065000 Transceiver 10BASE5, #20-4pr, FPO, PVC Jkt, CM - Blue, Light

$67,519.99
SKU:
9892 0065000
Shipping:
Calculated at Checkout
Color:
Blue, Light
Manufacturer Status:
Active
Product Family:
9892
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Belden 9892 0065000 Transceiver 10BASE5, #20-4pr, FPO, PVC Jkt, CM

IEEE 802.3 Ethernet Transceiver 10BASE5, 20 AWG stranded (7x28) tinned copper conductors, Datalene® insulation, 4 twisted pairs, overall polyester isolation tape + a tinned copper braid shield (95% coverage), drain wire, PVC jacket.

Ordering Details

  • Manufacturer Part Number: 9892 0065000
  • Color: Blue, Light
  • UPC/EAN: 612825260127
  • Manufacturer Footnote: C

Product Overview

  • Suitable Applications: IEEE 802.3 Transceiver Cable

Construction Details

  • Element: Pair(s); Size: 20; Stranding: 7x28; Material: TC - Tinned Copper; No. of Pairs: 4
  • Material: PE - Polyethylene (Foam); Nom. Insulation Diameter: 0.077 in (2.0 mm); Color Code: Gray & White, Yellow & Orange, Blue & Green, Black & Red; Notes: HDPE
  • Shield Type: Tape; Material: Bi-Laminate (Alum+Poly); Coverage: 100%
  • Shield Type: Braid; Material: Tinned Copper (TC); Coverage: 95%; Drainwire Type: 22 AWG (7x30) TC
  • Material: PVC - Polyvinyl Chloride; Nom. Diameter: 0.398 in (10.1 mm)

Electrical Characteristics

  • Nom. Characteristic Impedance: 78 Ohm
  • Max. Delay Skew: 78 ns/100m; Nom. Velocity of Prop.: 78%
  • Max. Insertion Loss (Attenuation): 6 dB/100m
  • UL Voltage Rating: 30 V (AWM 2919), 300 V (CL2)

Mechanical Characteristics

  • UL Temperature: 80°C; Operating: -40°C To +80°C
  • Stationary Min.: 3.98 in (101 mm); Installation Min.: 3.98 in (101 mm)
  • Max. Pull Tension: 175 lbs (79.4 kg)
  • Bulk Cable Weight: 93 lbs/1000ft

Standards and Compliance

  • Flammability / Reaction to Fire: UL1685 UL Loading, FT4, IEC 60332-1-2
  • CPR Compliance: CPR Euroclass: Eca
  • NEC / UL Compliance: Article 725, Article 800, CL2, CM
  • AWM Compliance: AWM 2919
  • CEC / C(UL) Compliance: CM
  • IEEE Compliance: IEEE 802.3
  • European Directive Compliance: EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
  • UK Regulation Compliance: UKCA Mark
  • APAC Compliance: China RoHS II (GB/T 26572-2011)
  • Other Standard Compliance(s): DEC Part No. 17-01320-00
  • Plenum Number: 89901

History

  • Update and Revision: Revision Number: 0.477 Revision Date: 09-07-2025
  • Footnote: C - CRATE REEL PUT-UP.
