Description
Belden 9804 060100 RS232/422 Low Cap, #28-2pr, PP, O/A Foil+Braid, PVC Jkt, CL2, 100Ω
Computer EIA RS-232/422 Cable, 2-Pair, 28 AWG stranded (7x36) tinned copper conductors, polypropylene insulation, overall Beldfoil® (100% coverage) + tinned copper braid shield (90% coverage), 28 AWG stranded tinned copper drain wire, PVC jacket.
Ordering Details
- Manufacturer Part Number: 9804 060100
- Color: Chrome
- Length: 100 ft
- Put-Up: Reel
- UPC/EAN: 612825258742
Supplied as one 100 ft Reel.
Product Overview
- Suitable Applications: RS-232 extended distance applications; RS-422 applications; computer communications; low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; panel wiring
Construction Details
- Element: Pair(s); No. of Elements: 2; Size: 28 AWG; Stranding: 7x36; Material: TC - Tinned Copper
- Element: Pair(s); Material: PP - Polypropylene; Nom. Thickness: 0.009 in (0.23 mm); Nom. Insulation Diameter: 0.033 in (0.84 mm); Color Code: Black & Red, Black & White
- Shield Type: Tape; Material: Bi-Laminate (Alum+Poly); Coverage: 100%; Drainwire Type: 28 AWG (7x36) TC
- Shield Type: Braid; Material: Tinned Copper (TC); Coverage: 90%
- Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.042 in (1.1 mm); Nom. Diameter: 0.214 in (5.44 mm)
- Overall Cable Diameter (Nominal): 0.214 in (5.44 mm)
Electrical Characteristics
- Element: Pair(s); Nom. Conductor DCR: 73.5 Ohm/1000ft; Nom. Capacitance Cond-to-Cond: 16.5 pF/ft (54.1 pF/m); Nom. Capacitance Cond-to-Other (Conds + Shield): 27.5 pF/ft (90.2 pF/m); Nom. Characteristic Impedence: 100 Ohm; Nom. Delay: 1.4 ns/ft; Nom. Inductance: 0.19 µH/ft (0.62 µH/m); Nom. Velocity of Prop.: 66%; Max. Current: 1 Amp per Conductor at 25ºC
- Nom Outer Shield DCR: 6.5 Ohm/1000ft (21 Ohm/km)
- UL Voltage Rating: 30 V
Mechanical Characteristics
- UL Temperature: 60°C; Operating: -30°C to +60°C
- Stationary Min.: 2.1 in (53 mm); Installation Min.: 2.1 in (53 mm)
- Max. Pull Tension: 38 lbs (17 kg)
- Bulk Cable Weight: 29 lbs/1000ft
Standards and Compliance
- Environmental Suitability: Indoor
- Flammability / Reaction to Fire: UL 1685 FT4 Loading, IEC 60332-1-2
- CPR Compliance: CPR Euroclass: Eca
- NEC / UL Compliance: Article 725, CL2
- AWM Compliance: AWM 2960
- European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
- UK Regulation Compliance: UKCA Mark
- APAC Compliance: China RoHS II (GB/T 26572-2011)
History
- Update and Revision: Revision Number: 0.502 Revision Date: 09-07-2025
- Footnote: C - CRATE REEL PUT-UP.
