Description
Belden 9328 0601000 High Perform Instr, 2 Pr #22 Str TC, PVC Ins E2, IS, PVC Jkt, PLTC
High Performance Instrumentation, 2 Pair 22AWG (7x30) Tinned Copper, PVC Insulation E2 Color Code, Individual Beldfoil® Shield, PVC Outer Jacket, PLTC
Ordering Details
- Manufacturer Part Number: 9328 0601000
- Color: Chrome
- UPC/EAN: 612825230144
- Manufacturer Footnote: C
Image is for illustration only. Actual cable color and packaging may vary. Refer to the listed color, length, and put-up for this part number.
Product Overview
- Suitable Applications: Industrial Control, Raceways Cable trays and ducts, Digital Control, Instruments (4-20ma, 0-10v, ...),low voltage digital control (24v, …), encoders, control circuits, distributed control
Construction Details
- Element: Pair(s); No. of Elements: 2; Size: 22; Stranding: 7x30; Material: TC - Tinned Copper
- Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.017 in (0.43 mm); Nom. Insulation Diameter: 0.062 in (1.6 mm); Color Code: Black, Red and Numbered
- Element: Each Pair; Shield Type: Tape; Material: Bi-Laminate (Alum+Poly); Coverage: 100%; Drainwire Type: 22 AWG (7x30) TC
- Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.042 in (1.1 mm); Nom. Diameter: 0.323 in (8.20 mm); Ripcord: Yes
Electrical Characteristics
- Nom. Conductor DCR: 18.2 Ohm/1000ft; Nom. Inner Shield DCR: 2.1 Ohm/1000ft (6.9 Ohm/km); Nom. Capacitance Cond-to-Cond: 30 pF/ft (98 pF/m); Nom. Capacitance Cond-to-Other (Conds + Shield): 54 pF/ft (180 pF/m); Nom. Inductance: 0.21 µH/ft (0.69 µH/m); Max. Current: 3.8 Amps per Conductor at 25ºC
- UL Voltage Rating: 300 V (PLTC)
Mechanical Characteristics
- UL Temperature: 105°C; Operating: -30°C To +105°C
- Stationary Min.: 3.23 in (82.0 mm); Installation Min.: 3.23 in (82.0 mm)
- Max. Pull Tension: 45.5 lbs (20.6 kg)
- Bulk Cable Weight: 42 lbs/1000ft
Standards and Compliance
- Environmental Suitability: Indoor, Outdoor, Sunlight Resistance
- Flammability / Reaction to Fire: UL 1685 FT4 loading, FT4, IEEE 1202 FT4
- NEC / UL Compliance: Article 725, Article 727, Article 800, CMG, ITC, PLTC
- AWM Compliance: AWM 2464
- CEC / C(UL) Compliance: CMG
- European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
- APAC Compliance: China RoHS II (GB/T 26572-2011)
History
- Update and Revision: Revision Number: 0.610 Revision Date: 04-10-2026
- Footnote: C - CRATE REEL PUT-UP., Z - FINAL PUT-UP MAY VARY (= OR -) 10% FOR SPOOLS OR REELS AND (+ OR -) 5% FOR UNREEL CARTONS FROM LENGTH SHOWN.
