Belden 8778 060250 Audio, Control & Instrument, #22-6pr, PP, Indiv. Foil, PVC Jkt, CM - Chrome, 250 ft Reel

$2,068.99
SKU:
8778 060250
Shipping:
Calculated at Checkout
Color:
Chrome
Length:
250 ft
Put-Up:
Reel
Manufacturer Status:
Active
Product Family:
8778
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Belden 8778 060250 Audio, Control & Instrument, #22-6pr, PP, Indiv. Foil, PVC Jkt, CM

Audio, Control & Instrument Cable, 6-Pair, 22 AWG stranded (7x30) tinned copper conductor, polypropylene insulation, individually shielded pairs with Beldfoil® (100% coverage), overall PVC jacket and 22 AWG stranded tinned copper drain wire.

Ordering Details

  • Manufacturer Part Number: 8778 060250
  • Color: Chrome
  • Length: 250 ft
  • Put-Up: Reel
  • UPC/EAN: 612825216261
  • Manufacturer Footnote: C

Supplied as one 250 ft Reel.

Product Overview

  • Suitable Applications: low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; computer communication; panel wiring

Construction Details

  • Element: Pair(s); No. of Elements: 6; Size: 22 AWG; Stranding: 7x30; Material: TC - Tinned Copper
  • Element: Pair(s); Material: PP - Polypropylene; Nom. Thickness: 0.011 in (0.28 mm); Nom. Insulation Diameter: 0.05 in (1.3 mm); Color Code: Black & Red, Black & White, Black & Green, Black & Blue, Black & Yellow, Black & Brown
  • Element: Pair(s); Shield Type: Tape; Material: Bi-Laminate (Alum+Poly); Coverage: 100%; Drainwire Type: 22 AWG (7x30) TC; Notes: each pair
  • Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.034 in (0.86 mm); Nom. Diameter: 0.352 in (8.94 mm)
  • Overall Cable Diameter (Nominal): 0.352 in (8.94 mm)

Electrical Characteristics

  • Element: Pair(s); Nom. Conductor DCR: 18.2 Ohm/1000ft; Nom. Inner Shield DCR: 12.39 Ohm/1000ft (40.65 Ohm/km); Nom. Capacitance Cond-to-Cond: 30 pF/ft (98 pF/m); Nom. Capacitance Cond-to-Other (Conds + Shield): 55 pF/ft (180 pF/m); Nom. Characteristic Impedence: 50 Ohm; Nom. Inductance: 0.18 µH/ft (0.59 µH/m); Nom. Velocity of Prop.: 66%; Max. Current: 1.96 Amps per Conductor at 25ºC
  • Typical Unbalanced NEXT %: 10.8 MHz
  • UL Voltage Rating: 300 V (CM), 30 V (UL AWM 2919)

Mechanical Characteristics

  • UL Temperature: 80°C; Operating: -20°C to +80°C
  • Stationary Min.: 3.5 in (89 mm); Installation Min.: 3.5 in (89 mm)
  • Max. Pull Tension: 127 lbs (57.6 kg)
  • Bulk Cable Weight: 70 lbs/1000ft

Standards and Compliance

  • Environmental Suitability: Indoor
  • Sustainability: CA Prop 65
  • Flammability / Reaction to Fire: UL 1685 FT4 Loading, IEC 60332-1-2
  • CPR Compliance: CPR Euroclass: Eca; CPR UKCA Class: Eca
  • NEC / UL Compliance: Article 800, CM
  • AWM Compliance: AWM 2919
  • CEC / C(UL) Compliance: CM
  • European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
  • UK Regulation Compliance: UKCA Mark
  • APAC Compliance: China RoHS II (GB/T 26572-2011)
  • Plenum Number: 88778, 82778, 87778

History

  • Update and Revision: Revision Number: 0.606 Revision Date: 09-07-2025
  • Footnote: C - CRATE REEL PUT-UP.
