Belden 6500PE 0101000 Security & Sound, 2 Conductor 22 AWG, TC, CMP - Black, 1,000 ft Reel

$465.99
SKU:
6500PE 0101000
Shipping:
Calculated at Checkout
Color:
Black
Length:
1,000 ft
Put-Up:
Reel
Manufacturer Status:
Active
Product Family:
6500PE
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Belden 6500PE 0101000 Security & Sound, 2 Conductor 22 AWG, TC, CMP

Security & Commercial Audio Cable, Plenum-CMP, 2-22 AWG stranded tinned copper pairs with Flamarrest® insulation, Beldfoil® shield and Flamarrest® jacket with ripcord

Ordering Details

  • Manufacturer Part Number: 6500PE 0101000
  • Color: Black
  • Length: 1,000 ft
  • Put-Up: Reel
  • UPC/EAN: 612825177425

Supplied as one 1,000 ft Reel.

Image is for illustration only. Actual cable color and packaging may vary. Refer to the listed color, length, and put-up for this part number.

Product Overview

  • Suitable Applications: Intercom/PA Systems and Sound/Audio Systems

Construction Details

  • Element: Conductor(s); No. of Elements: 2; Size: 22 AWG; Stranding: 7x30; Material: TC - Tinned Copper
  • Element: Conductor(s); Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.01 in (0.25 mm); Nom. Insulation Diameter: 0.048 in (1.2 mm); Color Code: Black, Red
  • Shield Type: Tape; Material: Bi-Laminate (Alum+Poly); Coverage: 100%; Drainwire Type: 24 AWG (7x32) TC
  • Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.015 in (0.38 mm); Nom. Diameter: 0.13 in; Ripcord: Yes
  • Overall Cable Diameter (Nominal): 0.13 in

Electrical Characteristics

  • Nom. Conductor DCR: 16.4 Ohm/1000ft; Nom. Capacitance Cond-to-Cond: 55 pF/ft (180 pF/m); Nom. Capacitance Cond-to-Other (Conds + Shield): 99 pF/ft (320 pF/m); Nom. Inductance: 0.18 µH/ft (0.59 µH/m); Max. Current: 2.8 Amps per Conductor at 25ºC
  • Nom Outer Shield DCR: 16.75 Ohm/1000ft (54.95 Ohm/km)
  • UL Voltage Rating: 300 V

Mechanical Characteristics

  • UL Temperature: 75°C; Operating: -20°C To +75°C
  • Stationary Min.: 1.3 in (33 mm); Installation Min.: 1.3 in
  • Max. Pull Tension: 24 lbs (11 kg)
  • Bulk Cable Weight: 11 lbs/1000ft

Standards and Compliance

  • Environmental Suitability: Indoor - Plenum, Indoor
  • Flammability / Reaction to Fire: NFPA 262 (UL 910), FT6
  • NEC / UL Compliance: Article 800, CMP
  • CEC / C(UL) Compliance: CMP
  • European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
  • APAC Compliance: China RoHS II (GB/T 26572-2011)

Product Notes

  • Notes: The jacket and shield are bonded so both can be removed on automatic stripping equipment. Drain wire is inside foil shield.

History

  • Update and Revision: Revision Number: 0.485 Revision Date: 09-07-2025
