Belden 6500FE 009U1000 Security & Sound, 2 Conductor 22 AWG, BC, Shielded, CMP - White, 1,000 ft UnReel

$252.99
SKU:
6500FE 009U1000
Shipping:
Calculated at Checkout
Color:
White
Length:
1,000 ft
Put-Up:
UnReel
Manufacturer Status:
Active
Product Family:
6500FE
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Belden 6500FE 009U1000 Security & Sound, 2 Conductor 22 AWG, BC, Shielded, CMP

Security & Commercial Audio Cable, Plenum-CMP, 2-22 AWG stranded bare copper conductors with Flamarrest® insulation, Beldfoil® shield and Flamarrest® jacket with ripcord

Ordering Details

  • Manufacturer Part Number: 6500FE 009U1000
  • Color: White
  • Length: 1,000 ft
  • Put-Up: UnReel
  • UPC/EAN: 612825177272

Supplied as one 1,000 ft UnReel.

Product Overview

  • Suitable Applications: Intercom/PA Systems and Sound/Audio Systems

Construction Details

  • Element: Conductor(s); No. of Elements: 2; Size: 22 AWG; Stranding: 7x30; Material: BC - Bare Copper
  • Element: Conductor(s); Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.009 in (0.23 mm); Nom. Insulation Diameter: 0.047 in (1.2 mm); Color Code: Black, Red
  • Shield Type: Tape; Material: Bi-Laminate (Alum+Poly); Coverage: 100%; Drainwire Type: 24 AWG (7x32) TC
  • Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.015 in (0.38 mm); Nom. Diameter: 0.128 in (3.25 mm); Ripcord: Yes
  • Overall Cable Diameter (Nominal): 0.128 in (3.25 mm)

Electrical Characteristics

  • Element: Conductor(s); Nom. Conductor DCR: 16.9 Ohm/1000ft; Nom. Capacitance Cond-to-Cond: 55 pF/ft (180 pF/m); Nom. Capacitance Cond-to-Other (Conds + Shield): 99 pF/ft (320 pF/m); Nom. Inductance: 0.17 µH/ft (0.56 µH/m); Max. Current: 6 Amps per Conductor at 25ºC
  • Nom Outer Shield DCR: 15.3 Ohm/1000ft (50.2 Ohm/km)
  • UL Voltage Rating: 300 V

Mechanical Characteristics

  • UL Temperature: 75°C; Operating: 0°C to +75°C
  • Stationary Min.: 1.3 in (33 mm); Installation Min.: 1.3 in (33 mm)
  • Max. Pull Tension: 24 lbs (11 kg)
  • Bulk Cable Weight: 11 lbs/1000ft

Standards and Compliance

  • Environmental Suitability: Indoor - Plenum, Indoor
  • Flammability / Reaction to Fire: NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2
  • CPR Compliance: CPR Euroclass: Eca
  • NEC / UL Compliance: Article 800, CMP
  • CEC / C(UL) Compliance: CMP
  • European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
  • UK Regulation Compliance: UKCA Mark
  • APAC Compliance: China RoHS II (GB/T 26572-2011)
  • Non-Plenum Number: 5500FE

History

  • Update and Revision: Revision Number: 0.529 Revision Date: 09-07-2025
  • Footnote: C - CRATE REEL PUT-UP.

Resources

Belden 6500FE Product Information
