Description
Belden 6200FE 0071000 Security & Sound, 2 Conductor 16 AWG BC, Shielded, CMP
Security & Commercial Audio Cable, 2-16 AWG stranded (19x29) bare copper conductors with Flamarrest® insulation, Beldfoil® shield, Plenum-CMP, Flamarrest® jacket with ripcord
Ordering Details
- Manufacturer Part Number: 6200FE 0071000
- Color: Violet
- Length: 1,000 ft
- Put-Up: Reel
- UPC/EAN: 612825350262
Supplied as one 1,000 ft Reel.
Product Overview
- Suitable Applications: Security Systems, Intercom/PA Systems, Sound/Audio Systems, Power Limited Controls
Construction Details
- Element: Conductor(s); No. of Elements: 2; Size: 16 AWG; Stranding: 19x29; Material: BC - Bare Copper
- Element: Conductor(s); Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.009 in (0.23 mm); Nom. Insulation Diameter: 0.075 in (1.9 mm); Color Code: Black, Red
- Shield Type: Tape; Material: Bi-Laminate (Alum+Poly); Coverage: 100%; Drainwire Type: 24 AWG (7x32) TC
- Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.015 in (0.38 mm); Nom. Diameter: 0.184 in (4.67 mm); Ripcord: Yes
- Overall Cable Diameter (Nominal): 0.184 in (4.67 mm)
Electrical Characteristics
- Element: Conductor(s); Nom. Conductor DCR: 4 Ohm/1000ft; Nom. Capacitance Cond-to-Cond: 81.5 pF/ft (267 pF/m); Nom. Capacitance Cond-to-Other (Conds + Shield): 146.7 pF/ft (481.3 pF/m); Nom. Inductance: 0.15 µH/ft (0.49 µH/m); Max. Current: 18 Amps per conductor @ 25°C
- Nom Outer Shield DCR: 15.9 Ohm/1000ft (52.2 Ohm/km)
- UL Voltage Rating: 300 V
Mechanical Characteristics
- UL Temperature: 75°C; Operating: 0°C to +75°C
- Stationary Min.: 1.8 in (46 mm); Installation Min.: 1.8 in (46 mm)
- Max. Pull Tension: 84 lbs (38 kg)
- Bulk Cable Weight: 31 lbs/1000ft
Standards and Compliance
- Environmental Suitability: Indoor - Plenum, Indoor
- Flammability / Reaction to Fire: NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2
- CPR Compliance: CPR Euroclass: Eca
- NEC / UL Compliance: Article 800, CMP
- CEC / C(UL) Compliance: CMP
- European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
- UK Regulation Compliance: UKCA Mark
- APAC Compliance: China RoHS II (GB/T 26572-2011)
- Non-Plenum Number: 5200FH
History
- Update and Revision: Revision Number: 0.527 Revision Date: 09-07-2025
- Footnote: C - CRATE REEL PUT-UP.
