Belden 6000UE 8771000 Security & Sound, 2 Conductor 12 AWG BC, CL2P - Natural, 1,000 ft Reel

$1,482.99
SKU:
6000UE 8771000
Shipping:
Calculated at Checkout
Color:
Natural
Length:
1,000 ft
Put-Up:
Reel
Manufacturer Status:
Active
Product Family:
6000UE
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Belden 6000UE 8771000 Security & Sound, 2 Conductor 12 AWG BC, CL2P

Security & Commercial Audio Cable, Plenum-CL2P 2-12 AWG stranded bare copper conductors with Flamarrest® insulation, Flamarrest® jacket with ripcord

Ordering Details

  • Manufacturer Part Number: 6000UE 8771000
  • Color: Natural
  • Length: 1,000 ft
  • Put-Up: Reel
  • UPC/EAN: 612825166115
  • Manufacturer Footnote: C

Supplied as one 1,000 ft Reel.

Product Overview

  • Suitable Applications: Intercom/PA Systems, Sound/Audio Systems

Construction Details

  • Element: Conductor(s); No. of Elements: 2; Size: 12 AWG; Stranding: 19x25; Material: BC - Bare Copper
  • Element: Conductor(s); Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.011 in (0.28 mm); Nom. Insulation Diameter: 0.113 in (2.87 mm); Color Code: Black, White
  • Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.015 in (0.38 mm); Nom. Diameter: 0.252 in (6.40 mm); Ripcord: Yes
  • Overall Cable Diameter (Nominal): 0.252 in (6.40 mm)

Electrical Characteristics

  • Element: Conductor(s); Nom. Conductor DCR: 1.6 Ohm/1000ft (5.2 Ohm/km); Nom. Capacitance Cond-to-Cond: 36 pF/ft (120 pF/m); Nom. Inductance: 0.14 µH/ft (0.46 µH/m); Max. Current: 30 Amps per conductor @ 25°C
  • UL Voltage Rating: 300 V

Mechanical Characteristics

  • UL Temperature: 75°C; Operating: 0°C to +75°C
  • Stationary Min.: 2.5 in (64 mm); Installation Min.: 2.5 in (64 mm)
  • Max. Pull Tension: 152 lbs (68.9 kg)
  • Bulk Cable Weight: 52 lbs/1000ft (77 kg/km)

Standards and Compliance

  • Environmental Suitability: Indoor - Plenum, Indoor
  • Flammability / Reaction to Fire: NFPA 262, UL 910 (Plenum), IEC 60332-1-2
  • CPR Compliance: CPR Euroclass: Eca
  • NEC / UL Compliance: Article 725, Article 760, CL2P, FPLP
  • European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
  • UK Regulation Compliance: UKCA Mark
  • APAC Compliance: China RoHS II (GB/T 26572-2011)
  • Non-Plenum Number: 5000UH

History

  • Update and Revision: Revision Number: 0.662 Revision Date: 10-12-2026
  • Footnote: C - CRATE REEL PUT-UP.

Resources

Belden 6000UE Product Information
