Belden 5504UE 008500 Security & Sound, #22-6c BC, CMR - Gray

$143.99
SKU:
5504UE 008500
Shipping:
Calculated at Checkout
Color:
Gray
Manufacturer Status:
Active
Product Family:
5504UE
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Belden 5504UE 008500 Security & Sound, #22-6c BC, CMR

Security & Sound Cable, Riser-CMR, 6-22 AWG stranded bare copper conductors with polypropylene insulation, PVC jacket with ripcord

Ordering Details

  • Manufacturer Part Number: 5504UE 008500
  • Color: Gray
  • UPC/EAN: 612825163817

Product Overview

  • Suitable Applications: Security System, Intercom/PA, Audio/Speaker, Power-Limited Controls

Construction Details

  • Element: Conductor(s); No. of Elements: 6; Size: 22 AWG; Stranding: 7x30; Material: BC - Bare Copper
  • Element: Conductor(s); Material: PP - Polypropylene; Nom. Thickness: 0.008 in (0.20 mm); Nom. Insulation Diameter: 0.045 in (1.1 mm); Color Code: Black, Red, White, Green, Brown, Blue
  • Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.017 in (0.43 mm); Nom. Diameter: 0.168 in (4.27 mm); Ripcord: Yes
  • Overall Cable Diameter (Nominal): 0.168 in (4.27 mm)

Electrical Characteristics

  • Element: Conductor(s); Nom. Conductor DCR: 16.9 Ohm/1000ft; Nom. Capacitance Cond-to-Cond: 17 pF/ft (56 pF/m); Max. Current: 4.2 Amps per Conductor @ 25°C
  • UL Voltage Rating: 300 V

Mechanical Characteristics

  • UL Temperature: 75°C; Operating: -20°C to +75°C
  • Stationary Min.: 1.7 in (43 mm); Installation Min.: 1.7 in (43 mm)
  • Max. Pull Tension: 55 lbs (25 kg)
  • Bulk Cable Weight: 19 lbs/1000ft

Standards and Compliance

  • Environmental Suitability: Indoor - Riser, Indoor
  • Flammability / Reaction to Fire: UL 1666 Riser, IEEE 1202 FT4, IEC 60332-1-2
  • CPR Compliance: CPR Euroclass: Eca
  • NEC / UL Compliance: Article 800, CMR
  • CEC / C(UL) Compliance: CMG
  • European Directive Compliance: EU CE Mark
  • UK Regulation Compliance: UKCA Mark
  • Plenum Number: 6504UE

History

  • Update and Revision: Revision Number: 0.435 Revision Date: 09-07-2025
  • Footnote: C - CRATE REEL PUT-UP.
