Description
Belden 5320UL D151000 Fire Alarm, #18-2c BC, FPLR
Fire Alarm Cable, Riser-FPLR, 2-18 AWG solid bare copper conductors with polypropylene insulation, PVC jacket with ripcord
Ordering Details
- Manufacturer Part Number: 5320UL D151000
- Color: Blue
- UPC/EAN: 612825160465
- Manufacturer Footnote: C
Product Overview
- Suitable Applications: Fire Alarm, Monitor/Detection, Circuits: Audio, Control, Initiating, Notification
Construction Details
- Element: Conductor(s); No. of Elements: 2; Size: 18 AWG; Stranding: Solid; Material: BC - Bare Copper
- Element: Conductor(s); Material: PP - Polypropylene; Nom. Thickness: 0.007 in (0.18 mm); Nom. Insulation Diameter: 0.055 in (1.4 mm); Color Code: Black, Red
- Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.017 in (0.43 mm); Nom. Diameter: 0.143 in (3.63 mm); Ripcord: Yes
- Overall Cable Diameter (Nominal): 0.143 in (3.63 mm)
Electrical Characteristics
- Element: Conductor(s); Nom. Conductor DCR: 6.4 Ohm/1000ft; Nom. Capacitance Cond-to-Cond: 29 pF/ft (95 pF/m); Nom. Capacitance Cond-to-Shield: 29 pF/ft (95 pF/m); Nom. Inductance: 0.16 µH/ft (0.52 µH/m); Max. Current: 14 Amps per conductor @ 25°C
- UL Voltage Rating: 300 V
Mechanical Characteristics
- UL Temperature: 75°C; Operating: -20°C to +75°C
- Stationary Min.: 1.14 in (29.0 mm); Installation Min.: 1.14 in (29.0 mm)
- Max. Pull Tension: 39.2 lbs (17.8 kg)
- Bulk Cable Weight: 15 lbs/1000ft
Standards and Compliance
- Environmental Suitability: Indoor - Riser, Indoor
- Flammability / Reaction to Fire: UL 1666 Riser, IEEE 1202 FT4, IEC 60332-1-2
- CPR Compliance: CPR Euroclass: Eca
- NEC / UL Compliance: Article 760, FPLR
- European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
- UK Regulation Compliance: UKCA Mark
- APAC Compliance: China RoHS II (GB/T 26572-2011)
- Plenum Number: 6320UL
History
- Update and Revision: Revision Number: 0.439 Revision Date: 09-07-2025
- Footnote: C - CRATE REEL PUT-UP.
