Belden 5220FL D151000 Fire Alarm, #16-2c BC, Shielded, FPLR - Blue

$340.99
SKU:
5220FL D151000
Shipping:
Calculated at Checkout
Color:
Blue
Manufacturer Status:
Active
Product Family:
5220FL
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Belden 5220FL D151000 Fire Alarm, #16-2c BC, Shielded, FPLR

Fire Alarm Cable, Riser-FPLR, 2-16 AWG solid bare copper conductors with polypropylene insulation, overall Beldfoil® shield, PVC jacket with ripcord

Ordering Details

  • Manufacturer Part Number: 5220FL D151000
  • Color: Blue
  • UPC/EAN: 612825158301

Product Overview

  • Suitable Applications: Fire Alarm, Monitor/Detection, Circuits: Audio, Control, Initiating, Notification, Noisy Environment

Construction Details

  • Element: Conductor(s); No. of Elements: 2; Size: 16 AWG; Stranding: Solid; Material: BC - Bare Copper
  • Element: Conductor(s); Material: PP - Polypropylene; Nom. Thickness: 0.007 in (0.18 mm); Nom. Insulation Diameter: 0.065 in (1.7 mm); Color Code: Black, Red
  • Shield Type: Tape; Material: Bi-Laminate (Alum+Poly); Coverage: 100%; Drainwire Type: 24 AWG (Solid) TC
  • Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.017 in (0.43 mm); Nom. Diameter: 0.170 in (4.32 mm); Ripcord: Yes
  • Overall Cable Diameter (Nominal): 0.170 in (4.32 mm)

Electrical Characteristics

  • Element: Conductor(s); Nom. Conductor DCR: 3.9 Ohm/1000ft; Nom. Capacitance Cond-to-Cond: 65.5 pF/ft (215 pF/m); Nom. Capacitance Cond-to-Other (Conds + Shield): 118 pF/ft (387 pF/m); Nom. Inductance: 0.14 µH/ft (0.46 µH/m); Max. Current: 6.3 Amps per conductor @ 25°C
  • Nom Outer Shield DCR: 16.9 Ohm/1000ft (55.4 Ohm/km)
  • UL Voltage Rating: 300 V (FPLR)

Mechanical Characteristics

  • UL Temperature: 75°C; Operating: -20°C to +75°C
  • Stationary Min.: 1.7 in (43 mm); Installation Min.: 1.7 in (43 mm)
  • Max. Pull Tension: 75 lbs (34 kg)
  • Bulk Cable Weight: 23 lbs/1000ft

Standards and Compliance

  • Environmental Suitability: Indoor - Riser, Indoor
  • Flammability / Reaction to Fire: UL 1666 Riser, IEC 60332-1-2
  • CPR Compliance: CPR Euroclass: Eca
  • NEC / UL Compliance: Article 760, FPLR
  • European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
  • UK Regulation Compliance: UKCA Mark
  • APAC Compliance: China RoHS II (GB/T 26572-2011)
  • Plenum Number: 6220FL

History

  • Update and Revision: Revision Number: 0.465 Revision Date: 09-07-2025
  • Footnote: C - CRATE REEL PUT-UP.
