Belden 1671J 010500 Conformable Coax, 50 Ohm RG-405, 24 AWG Solid SCCS, Copper-Tin Composite Shield, PVC Jacket - Black, 500 ft Reel

$5,336.99
SKU:
1671J 010500
Shipping:
Calculated at Checkout
Color:
Black
Length:
500 ft
Put-Up:
Reel
Manufacturer Status:
Active
Product Family:
1671J
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Belden 1671J 010500 Conformable Coax, 50 Ohm RG-405, 24 AWG Solid SCCS, Copper-Tin Composite Shield, PVC Jacket

Conformable Coax, 50 Ohm, RG-405, 24 AWG Solid Silvered Copper Covered Steel Conductor, PTFE Insulation, Copper Tape + 100% Tin-Filled Composite Braid Shield, PVC Jacket

Ordering Details

  • Manufacturer Part Number: 1671J 010500
  • Color: Black
  • Length: 500 ft
  • Put-Up: Reel
  • UPC/EAN: 612825120339
  • Manufacturer Footnote: V

Supplied as one 500 ft Reel.

Image is for illustration only. Actual cable color and packaging may vary. Refer to the listed color, length, and put-up for this part number.

Product Overview

  • Suitable Applications: Microwave and other high frequency applications, Interconnect RF equipment, Radar equipment, Military communications

Construction Details

  • RG Type: 405
  • No. of Elements: 1; Size: 24 AWG; Stranding: Solid; Nom. Diameter: 0.0201 in; Material: SCCS - Silvered Copper Covered Steel
  • Material: PTFE - Polytetrafluoroethylene; Nom. Insulation Diameter: 0.062 in (1.6 mm); Color Code: White
  • Layer: 1; Outer Shield Type: Tape; Material: Bare Copper (BC); Material Trade Name: Beldfoil®; Coverage: 100%
  • Layer: 2; Outer Shield Type: Braid; Material: Tinned Copper (TC + Tin Filled); Coverage: 100%
  • Material: PVC - Polyvinyl Chloride; Nom. Diameter: 0.127 in (3.23 mm)
  • Overall Cable Diameter (Nominal): 0.127 in (3.23 mm)

Electrical Characteristics

  • Frequency: 500 MHz; Max. VSWR: 1.1:1
  • Frequency: 20000 MHz; Max. VSWR: 1.3:1
  • Frequency: 500 MHz; Nom. Attenuation: 15 dB/100ft
  • Frequency: 1000 MHz; Nom. Attenuation: 22.2 dB/100ft
  • Frequency: 2000 MHz; Nom. Attenuation: 32.8 dB/100ft
  • Frequency: 3000 MHz; Nom. Attenuation: 41.2 dB/100ft
  • Frequency: 5000 MHz; Nom. Attenuation: 54.9 dB/100ft
  • Frequency: 7000 MHz; Nom. Attenuation: 66.4 dB/100ft
  • Frequency: 10000 MHz; Nom. Attenuation: 81.2 dB/100ft
  • Frequency: 15000 MHz; Nom. Attenuation: 102.dB/100ft
  • Frequency: 18000 MHz; Nom. Attenuation: 113 dB/100ft
  • Frequency: 20000 MHz; Nom. Attenuation: 120 dB/100ft
  • Frequency: 500 MHz; Max. Power Rating: 180 W
  • Frequency: 1,000 MHz; Max. Power Rating: 119 W
  • Frequency: 2,000 MHz; Max. Power Rating: 79 W
  • Frequency: 3,000 MHz; Max. Power Rating: 62 W
  • Frequency: 5,000 MHz; Max. Power Rating: 46 W
  • Frequency: 7,000 MHz; Max. Power Rating: 37 W
  • Frequency: 10,000 MHz; Max. Power Rating: 30 W
  • Frequency: 15,000 MHz; Max. Power Rating: 24 W
  • Frequency: 18,000 MHz; Max. Power Rating: 21 W
  • Frequency: 20,000 MHz; Max. Power Rating: 20 W
  • Nom. Conductor DCR: 64.2 Ohm/1000ft (211 Ohm/km); Nom. Outer Shield DCR: 10.2 Ohm/1000ft (33.5 Ohm/km); Nom. Capacitance Cond-to-Shield: 29.5 pF/ft (96.8 pF/m); Nom. Characteristic Impedance: 50 Ohm; Nom. Velocity of Prop.: 70%
  • UL Voltage Rating: 30 V RMS; Voltage Rating: 1500 V RMS

Mechanical Characteristics

  • UL Temperature: 105°C; Operating: -40°C To +105°C
  • Stationary Min.: 1 in (25 mm); Installation Min.: .125 in (3.18 mm); Flexing Min.: .375 in (9.53 mm)
  • Max. Pull Tension: 26 lbs (12 kg)
  • Bulk Cable Weight: 16 lbs/1000 ft

Standards and Compliance

  • Environmental Suitability: Indoor/Outdoor, Indoor, Outdoor
  • Flammability / Reaction to Fire: Horizontal Wire
  • AWM Compliance: AWM 10245 (30 V 105°C)
  • European Directive Compliance: EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
  • APAC Compliance: China RoHS II (GB/T 26572-2011)

Product Notes

  • Notes: Teflon® is a registered trademark of E. I. duPont de Nemours and Co. used under license by Belden, Inc.

History

  • Update and Revision: Revision Number: 0.394 Revision Date: 02-20-2026
  • Footnote: V - 250' PUT-UP EXACT LENGTH MAXIMUM OF 3 PIECES, MINIMUM LENGTH 50'. 500' PUT-UP EXACT LENGTH MAXIMUM OF 5 PIECES, MINIMUM LENGTH 50'. 1000' PUT-UP EXACT LENGTH MAXIMUM OF 8 PIECES, MINIMUM LENGTH 50'.
