Product Overview
DESCRIPTION
Use AtlasIED 195 Series protective enclosures for recessed or surface mounting of 840 Series clock/speaker baffles. The 195 Series has 12 knockouts (four on both top and bottom, two at each end). Enclosures are constructed of 20-gauge CRS and are heavily undercoated to prevent mechanical resonances. Units contain a compartment divider to separate high and low voltage wiring. Models for surface application include an (SM) prefix and are finished in textured white epoxy to match the clock/speaker baffle panel. Recessed enclosures are finished with an epoxy coating.
FEATURES
- All Models Include Provisions for Easy Installation of Standard 8" Loudspeakers.
- Easy-to-Configure Standard Panels in Model NC850 Provide Custom Flexibility for Mounting Switches, Thermostat, and/or Lighting Controls.
- Recessed and Surface Mounting Styles Meet Installation Requirements.
- Reliable Design Installs Quickly in New or Retrofit Construction
APPLICATIONS
- All Models Include Provisions for Easy Installation of Standard 8" Loudspeakers.
- Easy-to-Configure Standard Panels in Model NC850 Provide Custom Flexibility for Mounting Switches, Thermostat, and/or Lighting Controls.
- Recessed and Surface Mounting Styles Meet Installation Requirements.
- Reliable Design Installs Quickly in New or Retrofit Construction
SPECIFICATIONS
| Height | 13 13/16" (35.08375 cm) |
| Width | 26 7/8" (68.2625 cm) |
| Depth | 3" (7.62 cm) |
| Shipping Weight | 8.50 lbs (3.86 kgs) |
| Mounts Baffle | 840-89A |
Other Information
Atlas orders require a $100 combined order minimum. Please contact us about possible orders under this amount.
