Product Overview
DESCRIPTION
The HT87 is a Industry standard, high quality transformer with audio grade laminations.
The unit offers low insertion loss (not to exceed 1.0dB) and full-range frequency response
(+1dB from 50Hz - 15kHz).
Primary taps are 1, 2, 4, and 8 watts.
Secondary impedance is 4Ω and 8Ω.
Model HT-87 is designed for use with 70.7-volt lines.
Primary taps are 1, 2, 4, and 8 watts.
Secondary impedance is 4Ω and 8Ω.
Model HT-87 is designed for use with 70.7-volt lines.
FEATURES
- Constructed with Audio Grade Laminations
- Frequency Response is 50Hz - 15KHz
- High Quality Matching Transformer with Only 0.6dB Insertion Loss
- Primary Taps of 1, 2, 4, & 8 Watts
SPECIFICATIONS
Other Information
Atlas orders require a $100 combined order minimum. Please contact us about possible orders under this amount.
DESCRIPTION
The HT87 is a Industry standard, high quality transformer with audio grade laminations.
The unit offers low insertion loss (not to exceed 1.0dB) and full-range frequency response
(+1dB from 50Hz - 15kHz).
Primary taps are 1, 2, 4, and 8 watts.
Secondary impedance is 4Ω and 8Ω.
Model HT-87 is designed for use with 70.7-volt lines.
Primary taps are 1, 2, 4, and 8 watts.
Secondary impedance is 4Ω and 8Ω.
Model HT-87 is designed for use with 70.7-volt lines.
FEATURES
- Constructed with Audio Grade Laminations
- Frequency Response is 50Hz - 15KHz
- High Quality Matching Transformer with Only 0.6dB Insertion Loss
- Primary Taps of 1, 2, 4, & 8 Watts
SPECIFICATIONS
Atlas orders require a $100 combined order minimum. Please contact us about possible orders under this amount.
