Product Overview
DESCRIPTION
CE-listed, six input, 200-watt mixer amplifier designed for distributed business paging and background music (BGM) systems featuring Push Here Diagnostic technology and Remote Input Selection Remote Level control. The AA50PHD-CE is CE certified for use in Europe (220V-240V) and other international locations requiring that safety listing.
FEATURES
- 50W into 25V/70.7V and 4Ω Loads
- Rear Mounted DIP Switch Allows Mute Receive for Inputs 2 and 3
- Contact Closure Mute Terminals
- Variable Mute Sensitivity Control for Input 1
- Preamp In for External Processors
- Line Output
- Remote Input Select (RIS)
- Remote Level Control
- Input Assignable Zone 2 Output
- Two Unbalanced, Summing Line Level Inputs
- Balanced Mic/Line/Tel Input w/ Phantom Power
- Automated Diagnostic System Test (Push Here Diagnostic®)
SPECIFICATIONS
- Frequency Response: 80Hz - 15kHz
- Connector Type: 4 Position Phoenix 3.5mm Pitch
- Power Output: Max. Average Power @ 80Hz-15kHz with .5% THD, 4Ω 50W RMS
- Height: 3.66" (93mm)
- Width: 8.27" (210mm)
- Depth: 10.87" (276mm)
- Weight: 10.5lb
- Shipping Weight: 12.4lb
- Voltage Compatibility: 220V - 240V
RESOURCES
Other Information
Atlas orders require a $100 combined order minimum. Please contact us about possible orders under this amount.
